Technical Parameters:
| Model | RE-2010 |
| Rotary Bottle | 1L 24# (standard size) |
| Collecting Bottle | 1L 35# (ball mill mouth) |
| Condenser | Vertical <p85*430mm |
| Charging Valve | 19# (standard size) |
| Rotating Speed | 20〜195rpm |
| Vacuum | -0.098Mpa |
| Temp. Range | RT~99’C |
| Temp. Accuracy | ±1°C |
| Stroke Height | 100mm+150mm(sliding + manual) |
| Rotary Motor | 40W |
| Heating Power | 1.5KW |
| Water Evaporating Speed | 20ml/min |
| Vacuum Sealing | Double sealing rings made of Teflon+ Viton materials |
| Shelf Material | Aluminum alloy |
| Chamber Material | Aluminum alloy +Teflon(p240* 140mm |
| Power Supply | AC220V+10%, 50Hz |
| External Size(W‘D*H) | 550*400*780-1040mm |
| Package Size(W*D*H) | 720*525*385mm |
| Gross Weight | 19kg |
| Standard Accessory | 1L Rotary Bottle*1, 1L Collecting Bottle* 1 |
| Optional Accessory | Rotary Bottle(500〜3000ml),Vacuum pump, Inclined condenser, Recirculating chiller |
